Description
Empire Flint Hill Log Set
The Flint Hill Vent Free Gas Log Set features richly detailed, hand-painted Ceramic Fiber logs mounted atop our Vent-Free Contour Burner. Includes glowing embers to add to the illusion of a real wood fire at any heat setting. This competitively priced log/burner is ideal for existing fireplaces and fireboxes and for new construction.
Features
Flint Hill Vent Free Log Set
-
These systems combine the burner and log set into one package. Because they require a minimum of just 12 inches firebox depth, these compact systems fit easily into most fireplaces.
- Available in LP and Natural Gas
- 18, 24 and 30-inch Vent-Free Burners – up to 40,000 Btu
- Millivolt (VFDR), Manual (VFDM), and Thermostat (VFDT) models
- Choose Whiskey River Refractory or Flint Hill Ceramic Fiber model
- Richly Detailed, Hand-Painted Ceramic Fiber Logs
-
- Contour Burner
- Glowing Embers
- Approved for use in any Certified Vent Free Firebox
- Approved for installation in an Existing Wood Burning Fireplace (with damper closed)
- Approved for installation as Vented Log Sets
- 5-PIECE LOGS - 18” AND 24”
- 7-PIECE LOGS - 30”
Specifications
Vent-Free Contour Burner
Model | Description |
Log Length (inches) |
Btu Input |
Front Width (inches) |
Rear Width (inches) |
Depth (inches) |
Height (inches) |
Ship Wt. (lb) |
Manual, Standing Pilot/Piezo | ||||||||
VFDM-18 | Contour Burner | 18 | 28,000 | 28 | 17 | 12 | 17 | 20 |
VFDM-24 | Contour Burner | 24 | 34,000 | 30 | 23 | 12 | 18 | 23 |
VFDM-30 | Contour Burner | 30 | 40,000 | 34 | 26 | 12 | 20 | 25 |
Millivolt, Standing Pilot with On/Off Switch and Thermostat Remote | ||||||||
VFDR-18 | Contour Burner | 18 | 28,000 | 28 | 17 | 12 | 17 | 21 |
VFDR-24 | Contour Burner | 24 | 34,000 | 30 | 23 | 12 | 18 | 23 |
VFDR-30 | Contour Burner | 30 | 40,000 | 34 | 26 | 12 | 20 | 27 |
Millivolt, Thermostat with Hi-Low Knob (no remote) | ||||||||
VFDT-18 | Contour Burner | 18 | 28,000 | 28 | 17 | 12 | 17 | 20 |
VFDT-24 | Contour Burner | 24 | 34,000 | 30 | 23 | 12 | 18 | 23 |
VFDT-30 | Contour Burner | 30 | 40,000 | 34 | 26 | 12 | 20 | 25 |
Details
Flint Hill Ceramic Fiber Vent Free Gas Logs Specifications and Details:
COLLECTION | Vent-Free Collection |
PRODUCT SIZES | 18", 24", and 30" |
BURNER STYLES | Vent-Free Contour Burners |
FUEL OPTIONS | Propane/Natural Gas |
Download Documents
Flint Hill Ceramic Fiber Gas Logs Downloadable Documents
Product FAQ
Where can Flint Hill gas log sets be installed?
- In masonry fireplaces
- Fireboxes approved for vent-free gas logs
- Fireplaces approved for vented gas logs
Where can Flint Hill gas log sets NOT be installed?
- As replacement logs for a direct vent fireplace or insert.
- Any fireplace not approved for vent-free gas logs
- On top of any burner system that is not designed for them
- In cities or municipalities that do not allow vent-free gas logs. If unsure, check with your local building department.
What is a Contour Burner?
- It's a burner system designed specifically for the White Mountain Hearth Flint Hill and Whiskey River gas logs only
- Includes glowing embers that give the illusion of a smoldering ember bed
What are the different burner types and control options?
Controls can be confusing! Your Contour burner system offers 3 different control options. (Images are for illustration purposes. Actual unit design may vary)
MANUAL BURNER HI-LOW-MED KNOB
- has a standing pilot (meaning the pilot remains lit when the unit is on or in "pilot" position)
- is not remote control compatible
- does not require a match to light
- adjust the height of the flame by turning the knob
MANUAL VALVE WITH THERMOSTAT AND HI/LOW KNOB (NO REMOTE)
- has a standing pilot
- is designed to maintain the temperature of the room
- is not remote compatible
- does not require a match to light
- turn the knob to set the desired temperature
- unit will come on an off by itself to maintain the temperature.
MILLIVOLT BURNER WITH ON/OFF SWITCH AND THERMOSTAT REMOTE
- has a standing pilot (meaning the pilot remains lit when the unit is on or in "pilot" position)
- has an on/off/remote switch
- can be operated by remote control or at the unit
- does not require a match to light
- has a knob to adjust the height of the flame
- thermostat remote will allow you to set the temperature of the logs. Many times, we are asked what is the difference between the Manual Valve with Thermostat and Hi/Lo knob and this Millivolt burner with on/off switch and thermostat remote. The main differences are this valve system will:
- allow you to attach a remote control
- allow you to turn off the unit and keep your pilot lit
- allow you to set the temperature from the remote control. You can override the temperature setting and have the unit either on or off.
How do I select the right size gas log?
Figuring out the right size gas logs for your fireplace is as easy.
- Measure the inside of your fireplace. Use this helpful measuring guide located in our Gas Log Learning Center
- Select your control system
-
Select the proper sized logs based on your measurements and desired control system
- Place your order!
Can I put these logs on my existing burner?
Only if you are placing these logs on the exact burner designed for them.
Should I buy the same size logs I already have?
We recommend you measure the inside of your fireplace and base your purchasing decision on the your fireplace measurements instead of measuring your existing gas logs. The reason? Because gas logs and burner systems may have different sizing requirements. In one style, you may need an 18" and in another style you may be able to fit a 24" inside of the same fireplace.
Why does the price seem to "jump" up after I select the Burner and Control System?
Your burner and control system is a complete hearth kit. It includes the burner pan, grate, sand/vermiculite (if needed), embers (if included), valve, and control system
I am still confused. LOL
No worries! We are here to help. During business hours, feel free to reach out to us via chat or give us a call at 734.707.6589 or 888.757.5344. You can also check out our Gas Log Learning Center and Buying Guide!
